Multipurpose Shredder / Four Shaft Waste Shredder/ Plastic Shredder

Working principle

In the process of the metal crusher, the material is fed into the sliding silo through the feeding conveyor, and the material is uniformly fed into the main cavity of the equipment through the forced pressing and pressing system; during the high-speed rotation of the main shaft, The material is crushed by the primary, and the crushed material is crushed into spherical metal particles by a roller press at a high speed in the machine compartment, and the scrap metal which reaches the discharge standard under the repeated impact is discharged out of the machine compartment through the bottom screen. The discharged raw materials are sent to a sorting system through a discharge conveyor to sort impurities, scrap iron, scrap copper, and scrap in the scrap metal to obtain high-quality raw materials, which can be used for regenerative metallurgical processing.The metal crusher uses the kinetic energy generated by the high-speed rotation of the blade to crush the scrap steel. In the crushing, the surface dirt such as rust and paint on the scrap steel surface can be peeled off, and then a certain piece of pure broken steel can be obtained under the action of the magnetic separation equipment.

Internal Structure of Four Shaft Shredder

1. Blade of shredder

Blade of shredder is divided into fixed blade and removed blade,fixed blade processes materials by that is fixed in shredder main shaft by its internal hexagon fixed hole.

2. Shredder main shaft

Hexagon interface shaft is connected with reducer by bearing and coupling.

3. Shredder body box

Shredder body box is used to install bearing and fix main shaft, and supplies closed space for four shaft shredder linkage and crushing.

4. Bearing

Bearing can reduce friction force by internal pressure cylinder when main shaft turns round, thus reduces torque loss.

5. Reducer

It can adjust motor output speed,reduce motor damage from main shaft concussion and increase main shaft torque by reducer.

Four Shaft Shredder Technical Parameters:

​

FAQ

1: How to pay to you ?

we accept the payment by T/T , Western Union , Cash, L/C, D/P and Money Gram .

2: How long is the delivery time?

For standard machines, it would be 5-7 days; For non-standard machines and customized machines according to clients specific requirements, it would be 30 days.We will arrange the production and shipment as soon as possible when we received the deposit, and update the information with the customer on line.

3: Can you offer us the necessary paper to do the customs clearance?

Yes, of course. We will send you the commercial invoice, sales contract,

packing list, bill of lading(FOB or CFR, CIF terms), insurance policy (if CIF terms), also CO if you need.

4: Contact Detail

Telephone: 86-10-67813859

Mobile Phone: 0086-15838025782

Welcome to contact us at any time We will reply you within 24 hours

Packing & Shipping

1) All the wear out spare parts are packed by plastic films and wooden boxes.
2) Wire cables are used for fastening the machines.
3) FCL: Shipping by standard exporting container.
2) LCL: Poly wood case.

Looking forward to cooperate with you !

HENAN DIANYAN NEW ENERGY TECHNOLOGY CO., LTD. is a professional manufacturer of industrial Shredder equipment, located in Zhenzhou City, China. Since 2006,we factory focused on the development and production of various types of shredder machinery.

The Company has established its wide range of cooperative relations with Kunming University of Science and Technology, Yunnan Agricultural University, Nanjing University of Science and Technology, Southwest Forestry University and other colleges and universities and Kun Dianyan Research Institute ( a science & Technology Institute supported and funded by Chinese Ministry of Science and Technology).

Factory Show:

Our main products include Plastic Shredder, Metal Shredder, Tyre Shredder, Wood Shredder, Garbage Shredder, and so on.

With 12 years development, now we have more than 100 employees, 12000 square meter workshop. Our Machine has exported to 30 countries, such as America, UK, India, Thailand, Chile, UAE, Egypt, and so on.

Customer Visiting:

Our Team:

Dianyan also has passed gained many certification, such as ISO 9001: 2008 ,CE and SGS.
